Features
．Investment casting
．Anti-staticdevice
．Blow-out proof stem
．ISO5211 Direct mounting pad
．Locking device hande
Product application industry
The product is suitable for industries such as petroleum, chemical, natural gas, biochemical, pharmaceutical, environmental protection, and new energy.
Technical Specification
DN:Full port，DN15～DN150
Body W.P:1000WOG (PN63)
Flange end W.P: PN16/40, CLASS 150/300
W.T:-20℃～180℃
Body Materia:WCB/CF8/CF8M
ANSI CLASS 150/300
Design: ASME B16.34
Flange dimension: ASME B16.5
Inspection&testing: API 598
DIN PN16/40
Design: DIN 3357, EN12516-1
Flange dimension: DIN 2543-2545，EN1092-1 PN16/40
Face to face: DIN 3202-F1, EN 558-1
Inspection&testing: DIN 3230, EN12266-1
