Product application industry

The product is suitable for industries such as petroleum, chemical, natural gas, biochemical, pharmaceutical, environmental protection, and new energy.

Technical Specification

DN:Full port，DN8～DN100

W.P:1000WOG (PN63)

W.T:-20℃～180℃

Body Materia:WCB/CF8/CF8M

Actuator:Pneumatic，Electric motor

Thread type：ASME B1.20.1 (NPT),

                 DIN 259/DIN 2999, BS21,

                 ISO 288-1, ISO 7-1

Socket weld type: ASME B16.11 & DIN3239 part2

Butt weld type: ASME B16.25 & DIN3239 part1
